We are the resin manufacturer you need!
Structures:Isophthalic
Processes:SMC Molding Resin
Application:Suitable for high performance SMC/BMC system Products, used in bathroom, automobile, electrical appliances, construction and other fields.
ZC-8509 resin is mainly composed of m-benzene, maleic anhydride, neopentyl glycol and other standard diols The raw material of isophene-neopentyl glycol type unsaturated polyester resin, dissolved in styrene crosslinked monomer It has high viscosity and high reactivity.
ZC-8509 resin has high heat resistance, water resistance, weather resistance, and good mechanical properties and stability It can be obtained by adding 9282 low profile agent and 9262 low shrinkage agent Low shrinkage, zero shrinkage effect can reach class A surface. Suitable for high performance SMC/BMC system Products, used in bathroom, automobile, electrical appliances, construction and other fields.
| Property | Value | Unit | TM |
| Appearance | Light yellow transparent viscous liquid | – | – |
| Acid Value | 9-15 | mgKOH/g | GB/T 2895-2008 |
| Viscosity，25℃ | 1.4-2.4 | Pa.s | GB/T 7193-2008 |
| Solid Content | 60-68 | % | GB/T 7193-2008 |
| Thermal Stability,80℃ | ≥24 | h | GB/T 7193-2008 |
| Gelation time 25℃ | 7-15 | min | GB/T 7193-2008 |
| Property | Value | Unit | TM |
| Appearance | The casting body is free from defects | – | – |
| Barcol hardness | 50 | – | GB/T 3854-2005 |
| HDT | 130 | ℃ | GB/T 1634-2004 |
| Break Elongation | 2 | Mpa | GB/T 2567-2008 |
| Tensile Strength | 60 | Mpa | GB/T 2567-2008 |
| Tensile Modulus | 3500 | Mpa | GB/T 2567-2008 |
| Flexural Strength | 110 | Mpa | GB/T 2567-2008 |
| Flexural Modulus | 3600 | Mpa | GB/T 2567-2008 |
ZC-8509 resin does not contain wax, does not contain accelerators and thixotropic additives.ZC-8509 is usually used in conjunction with 9282 in low shrink mold plastics. ZC-8509 is generally recommended The ratio with 9282 is 60:40, and can be adjusted according to the actual situation.in order to ensure the storage of SMC/BMC material, the production should be appropriate to add stabilizer.
Recommended formula of SMC initial paste:
| ZC-8509 Resin | 60 |
| 9282 Low shrinkage agent | 40 |
| TBPB | 1.5 |
| Zinc stearate | 4.5 |
| Heavy calcium carbonate | 180 |
| Light magnesium oxide | 0.88 |
Net weight 220 kilograms, metal drum.Please contact us.
