Structures:Additive Flame Retardant
Processes:Hand lay-up
Application:It is widely used for all kinds of flame retardant performance dedicated FRP products.
ZC-5009 Resin adds flame retardant and unsaturated polyester
Resin, has been soluble in the styrene crosslinker, has medium viscosity and medium reaction
active.
ZC-5009 resin has no halogen and low tobacco, which can meet the flame retardant requirements of the self -extinguishing of the fire, which is in line with the requirements of the railway industry standard TB/T3138-2006. Widely used for all kinds of flame retardant performance
Dedicated FRP products.
| Property | Value | Unit | TM |
| Appearance | – | – | – |
| Acid Value | 6-12 | mgKOH/g | GB/T 2895-2008 |
| Viscosity，25℃ | 0.6-0.8 | Pa.s | GB/T 7193-2008 |
| Solid Content | 75-83 | % | GB/T 7193-2008 |
| Thermal Stability,80℃ | ≥24 | h | GB/T 7193-2008 |
| Gel time | 5-18 | min | GB/T 7193-2008 |
| Property | Value | Unit | TM |
| Barcol Hardness | 60 | – | GB/T 3584-2005 |
| Flexural Strength | 260 | Mpa | GB/T 1449-2005 |
| Flexural Modulus | – | Mpa | GB/T 1449-2005 |
| Tensile Strength | 220 | Mpa | GB/T 1447-2005 |
| Tensile Modulus | – | Mpa | GB/T 1447-2005 |
| Property | Value | Unit | TM |
| Appearance | There are no defects of casting body | – | – |
| Barcol Hardness | 45 | Mpa | GB/T 3854-2005 |
| HDT | 70 | ℃ | GB/T 1634-2004 |
| Break Elongation | 0.8 | Mpa | GB/T 2567-2008 |
1. ZC-5009 resin has wax with wax and does not contain promoters.
2. ZC-5009 resin is sensitive to light, and it is easy to gel after seeing light. Therefore, it is necessary to avoid opening the package or exposed it in a strong light before use.
3. Recommendation of the curing system: 0.4-2.0%of pure cobalt promotion agent (not recommended to contain
There are colorless promoters with copper salt and potassium), and MEKP curing agent is 1.0-2.5%.
4. The adding filler’s settlement during the storage of flame retardant resin storage is normal. Before use, stir well.
Net weight is 80 kg.
