We are the resin manufacturer you need!

Polylite™ Unsaturated Polyester Resin ZC-DC191P Resin DCPD Resin Hand lay-up Resin

Structures:DCPD
Processes:Hand lay-up
Application: Suitable for ordinary fiberglass products, as well as repairing and strengthening stone materials.

+86 18136701732
Info@tritiumupr.com

Product Details

Chemical/Physical Nature

ZC-DC191P resin is an unsaturated polyester resin mainly composed of dicyclopentadiene, maleic anhydride, and standard diols. It is soluble in cross-linked monomers such as styrene and has moderate viscosity and reactivity.

Benefits and Application

ZC-DC191P resin has high solid content and low viscosity, good wettability with fiberglass, excellent mechanical properties of fiberglass, high strength, good water and heat resistance, and a wide range of applications. Suitable for ordinary fiberglass products, as well as repairing and strengthening stone materials.

Liquid Resin Typical Properties

PropertyValueUnitTM
AppearancePurple red ransparent viscous liquid––
Acid Value17-23mgKOH/gGB/T 2895-2008
Viscosity,25℃0.23-0.45Pa.sGB/T 7193-2008
Solid Content68-75%GB/T 7193-2008
Thermal Stability,80℃≥24hGB/T 7193-2008
Gelation time,25℃5-18minGB/T 7193-2008

Unfilled Castings Typical Properties

PropertyValueUnitTM
AppearanceNo defects in the casting body––
Babbitt Hardness40–GB/T 3854-2005
HDT85℃GB/T 1634-2004
Breake elongation2%GB/T 2567-2008
Tensile Strength50MpaGB/T 2567-2008
Tensile modulus3100MpaGB/T 2567-2008
Flexural strength90MpaGB/T 2567-2008
Flexural modulus3200MpaGB/T 2567-2008

FRP Typical Properties

PropertyValueUnitTM
Barcol Hardness66–GB/T 3584-2005
Flexural strength330MpaGB/T 1449-2005
Flexural modulus17000MpaGB/T 1449-2005
Tensile strength330MpaGB/T 1447-2005
Tensile modulus17000MpaGB/T 1447-2005

Application Guidelines

1. ZC-DC191P resin contains wax and accelerators, and does not contain thixotropic additives.
2. ZC-DC191P resin is sensitive to light and easy to gel after seeing light, so it should be avoided before use.
Avoid opening the packaging or exposing it to strong light.
3. Recommended curing system: MEKP curing agent 1.0-2.5%.

Package

Net weight 220 kilograms, in metal drums. Special packaging requirements, please contact us.
